The Discovery Drone Detection System is an advanced counter-drone solution designed for passive long-range detection and early warning of UAVs, safeguarding airspace against unauthorized drones.

Unlike conventional systems, Discovery operates without emitting signals, meaning it does not interfere with its surroundings. This non-intrusive design allows the system to accurately detect, classify, and track drones and their controllers over long distances, offering real-time early warning capabilities.

There are three Discovery models available, each differing only in detection range: the A1000 detects up to 2 km, the A2000 detects up to 5 km, and the A8000 detects up to 8 km under ideal weather conditions.

The system operates within an ultra-wideband frequency range from 300 MHz to 6 GHz, allowing it to scan and analyze protocols across a broad range of frequencies. This wide support ensures compatibility with more than 98% of drone models on the market. Additionally, the Discovery system functions through passive detection mode, meaning it only receives signals without transmitting. This makes it a non-intrusive solution, suitable for environments where there can be no interference with other electronic systems, such as airports, critical infrastructure, and entertainment venues.

The system includes blacklist/whitelist functionality, allowing you to manage drone activity more effectively. Known and authorized drones can be added to the whitelist, preventing unnecessary alarms, while unauthorized or suspicious drones are immediately flagged via the blacklist.

Discovery is highly accurate, capable of pinpointing the exact location of both drones and their pilots within a 10-meter range (RMS), and the system’s directional accuracy stands at 3°, ensuring precise geolocation even in complex environments. As it is designed with scalability in mind, a single Discovery sensor (A8000 model) can detect drones up to 8 kilometers away, depending on the weather conditions. Multiple sensors can be networked to extend this range, providing extensive coverage over large areas and its 360° omnidirectional detection ensures that the system covers every angle without blind spots. Discovery is also easily integrated with other security systems, such as radars and jamming technologies, for an enhanced defense infrastructure.

Discovery Drone Detection System Main Features:

• 3 models available: A1000, A2000, A8000
• Passive and accurate drone detection system
• Simultanous detection of up to 30 drones
• Wide frequency range from 300 MHz to 6 GHz covering over 98% of commercial drones
• Scalable and flexible deployment, with detection range up to 8 km and network integration for limitless range extension
• Location of both drone and pilot within a 10-meter range (RMS)
• 360° omnidirectional coverage for full airspace monitoring without blind spots
• Blacklist/whitelist functionality
• Non-intrusive passive detection that ensures zero interference with the environment
• Simple integration with other security systems such as radars and jamming systems

Discovery Drone Detection System Technical Specifications:

Technology: Deep Signal Inspection Gen 2
Range of Detection: Up to 2 km (A1000), 5 km (A2000), 8 km (A8000) (in ideal weather conditions)
Geolocalization for Drone: 10 m (RMS)
Geolocalization for Pilot: 10 m (RMS)
Detection Frequency: 300 MHz ~ 6 GHz Full band scanning, detection, display
Product Dimensions (DxH): Cylinder: D 220 mm, H 210 mm
Weight: 3 kg
Ingress Protection Rating: IP65
Operating Temperature: -20°C tp 55 °C
Power Supply: AC 100-240
Power Consumption: ≤ 35 W
Connectvity: LAN/Cellular
Configuration, Operation and Alarms: Bluvec WebUI
Software Updates: Local and/or Cloud
Data Storage: Local and/or Cloud
System Integration: GraphQL and RESTFUL based API interface
Interference with Other Systems: Zero interference
Simultaneous Detection: Up to 30 Drones
Directivity: 360 ° Omnidirectional

---

>>Download detailed specifications (PDF)<<
