The Handheld Discovery Mini is a portable anti-drone system that detects, identifies, and tracks unauthorized drones. It offers real-time tracking and pilot location features, ideal for securing public events, critical infrastructure, and private properties.

The device can detect drones within a range of up to 2 km and at heights of up to 1 km, with a positioning accuracy of less than 10 meters for both drones and their pilots. It can also simultaneously track more than 10 drones. This capability is essential in scenarios where multiple drones are deployed, such as during public events or over critical infrastructure.

For critical infrastructure protection, it keeps protected sensitive locations like power plants, airports, and government buildings against unauthorized surveillance by drones. In public events, the Discovery Mini helps ensure crowd safety by detecting unauthorized drones over stadiums or similar venues. It is also essential for private property and high-security facilities, offering protection from drone intrusions over private estates, secure institutions, or industrial facilities where surveillance from air could pose a significant risk.

Additionally, the Discovery Mini system doesn’t just detect drones—it tracks them in real-time with impressive speed, detecting drones within less than 1 second and refreshing its data at the same rate. This immediate feedback ensures that any unauthorized drone activity is identified and responded to without delay. It also offers blacklist and whitelist functionality, helping you filter out known, authorized drones and focus on the unknown and potential threats.

The system can be used independently or integrated into larger security systems, and it’s compatible with a wide range of interference equipment, including various types of stationary or handhel jamming systems.

Discovery Mini Handheld Main Features:

• Monitors 2.4 GHz and 5.8 GHz bands used by popular drones like DJI and Autel
• Real-time drone and pilot location identification on a live map with under 1-second response time
• Drone fingerprinting shows frequency, serial number, location, altitude, and flight path
• Detects drones up to 2 km away and 1 km high with 10-meter accuracy
• Tracks over 10 drones simultaneously
• Blacklist/Whitelist Filtering: Focuses on unauthorized drones, filtering out known devices
• Weighs only 550g, offering portable design for ease of transport and use
• 6-inch multi-touch touchscreen for easy handling
• Long battery life with up to 4 hours of use

Discovery Mini Handheld Technical Specifications:

Size (LxBxH): 41x33x19 cm
Weight: 12,8 kg
Frequency Range: 2.4GHz、5.8GHz
Main Frequency: 2.4GHz、5.8GHz
Simultaneous Detection: ≥ 10 Drones
Screen: 6 Inch Touch Screen
Sensitivity: ≥ -95dBm (25kHz)
Detection range: 1.5- 2 km
Detection Height: 0~1000m
Directional precision: ≤ 1.0° (RMS)
Positioning Accuracy: Positioning error for drone/pilots ≤ 10m
Detection Time: ≤ 1s
Refresh Time: ≤ 1s
Detection Success Rate: ≥ 99 %
Working Time: 4 hours

---
